HRD-804 Outdoor Customized Model Floor Stands LCD Advertising Player IK10 Vandalproof.
● IP65,IP66 level of advertising player.
● IK10 level. With CE,FCC,ROHS,ETL,BIS ceritification.
● With OMC Remote Maintenance Function.
● Build in CMS for remote control in CMS.
Share on facebook
Share on whatsapp
Share on twitter
Share on email
Share on linkedin
Specification
| Specification | ||||||
| No. | Components | Model | Details | |||
| 1 | Media Player | Windows media player controller (Android is optional if needed) | CPU | Intel Celereon QUAD core J1900 Processor (2.5GHz, QUAD Core) | ||
| GPU | Intel® HD Graphics for Intel Atom® Processor Z3700 Series Frequency(688MHz~854Mhz) | |||||
| DDR3 RAM | 4GB | |||||
| ROM | 128GB SSD(256GB optional) | |||||
| WIFI | High quality WiFi module included (802.11 B/G/N) | |||||
| Network Interface Card | 10/100/1000Mbits/sec Ethernet LAN connectivity | |||||
| OS | Windows 7/8/8.1/10 or Linux Ubuntu | |||||
| 2 | Panel | LG Glass | Screen size | 21.5 inch, 27 inch,32 inch,43 inch,49 inch,55 inch,65 inch,75 inch,84/86 inch,98 inch. | ||
| Brightness | 2500 cd/m2(1500cd/m2~5000 cd/m2 optional) | |||||
| Color depth | 16.7M/1.07B | |||||
| Angle | 178°/178° | |||||
| Contrast | 1300:1 | |||||
| Backlight tube life | more than 60,000 hours(5 years of constant brightness) | |||||
| Response Time | 8ms | |||||
| Max. resolution | 1920*1080 , 3840*2160(Optional) | |||||
| 3 | Cooling system | (Air conditioner and Cooling fans system+heater are optional) | Centrifugual fans built in | |||
| 4 | Power | Input Voltage | AC100V~240V 50 /60 HZ | |||
| Power Consumption | TBD | |||||
| Standby power consumption | <10W | |||||
| 5 | Enviroment | Work Temperature | 0-50℃ | |||
| Storage Temperature | -10-60℃ | |||||
| Work Humidity | 10%-90% | |||||
| Storage Humidity | 5%-95% | |||||
| 6 | OSD Language | English/Chinese Multi-Language Supported | ||||
| 7 | Speakers | OP‐100 | 2x10W, Waterproof | |||
| 8 | Casing | HUAER | Color | White,black and other color are optional | ||
| 1. IK10 and IP65 level outershell is made by galvanized sheet. 2. With a protection layer of high-penetrating Tempered glass (with 6mm thickness) on the surface of the LCD Panel. 3. Surface finishing: heavy industrial grade of powder coating with an anti-wear texture for Outdoor using. 4. Water-proof, dust-proof double layer outershell,vandal proof. |
||||||
| 9 | Security Configuration 1. Power management: Moudule Power control indivadually with Circuit Breaker 2. Environment camera 3. Filter block percentage detection sensor. 4. Door open sensor 5. Shock sensor and warning with photos upload. |
|||||
| 10 | Outdoor OMC system (outdoor maintenance and management cloud software system): 1.Every product inlcudes 10 kinds of sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor). 2. Problem and staus monitoring software included. 3.Touble shooting by software included. 4.Use softwae Remote Check key working performance by Group 5.Unnormal work alarm generation.Control interface supporting: 1. RS232 HUAER provide API and instruction protocol. 2. TCP/IP HUAER provide technical supporting.Cloud service supporting: 1.CMS :http://150.109.100.56 2.OMC:http://49.51.171.225 3.HUAER can support to help Customer to setup their own server. |
|||||
