Huer Display

HRD-836 43~86 inch Outdoor Advertising Display Anti-dust,Waterproof.

Item: HRD-836 Category: ,

• OEM&ODM supported
• IP65,IP66 level  of advertising player.
• IK10 level. With CE,FCC,ROHS,ETL,BIS ceritification.
• With OMC Remote Maintenance Function







Contact Supplier
Share on facebook
Share on whatsapp
Share on twitter
Share on email
Share on linkedin

Specification

Specification
No. Components Model  Details
1 Media Player Windows media player controller (Android is optional if needed) CPU Intel Celereon QUAD core J1900 Processor (2.5GHz, QUAD Core)
GPU Intel® HD Graphics for Intel Atom® Processor Z3700 Series   Frequency(688MHz~854Mhz)
DDR3 RAM 4GB
ROM 128GB SSD(256GB optional)
WIFI High quality WiFi module included (802.11 B/G/N)
Network Interface Card 10/100/1000Mbits/sec Ethernet LAN connectivity
OS Windows 7/8/8.1/10  or Linux Ubuntu
2 Panel LG Glass Screen size 43~86 inch
Brightness  2500 cd/m2(1500cd/m2~5000 cd/m2 optional)
Color depth 16.7M/1.07B
Angle 178°/178°
Contrast 1300:1
Backlight tube life more than 60,000 hours(5 years of constant brightness)
Response Time 8ms
Max. resolution 1920*1080 , 3840*2160(Optional)
3 Cooling system (Air conditioner and Cooling fans system+heater are optional) Centrifugual fans built in
4 Power Input Voltage AC100V~240V 50 /60 HZ
Power Consumption TBD
Standby power consumption <10W
5 Enviroment Work Temperature 0-50℃
Storage Temperature -10-60℃
Work Humidity 10%-90%
Storage Humidity 5%-95%
6 OSD Language English/Chinese Multi-Language Supported
7 Speakers OP‐100 2x10W, Waterproof
8 Casing HUAER Color White,black and other color are optional
1. IK10 and IP65 level outershell is made by galvanized sheet.
2. With a protection layer of high-penetrating Tempered glass (with 6mm thickness) on the surface of the LCD Panel.
3. Surface finishing: heavy industrial grade of powder coating with an anti-wear texture for Outdoor using.
4. Water-proof, dust-proof double layer outershell,vandal proof.
9 Security Configuration
1. Power management: Moudule Power control indivadually with Circuit Breaker
2. Environment camera
3. Filter block percentage detection sensor.
4. Door open sensor
5. Shock sensor and warning with photos upload.
10 Outdoor OMC system (outdoor maintenance and management cloud software system):
1.Every product inlcudes 10 kinds of sensors (light sensor, door openning sensor, humidity sensor, temperature sensor, vibration sensor, safety monitoring sensor, ponding sensor, smog sensor, collision sensor,tilt sensor).
2. Problem and staus monitoring software included.
3.Touble shooting by software included.
4.Use softwae Remote Check key working performance by Group
5.Unnormal work alarm generation.Control interface supporting:
1. RS232  HUAER provide API and instruction protocol.
2. TCP/IP  HUAER provide technical supporting.Cloud service supporting:
1.CMS :http://150.109.100.56
2.OMC:http://49.51.171.225
3.HUAER  can support to help Customer to setup their own server.
